Metamark MetaCast MDC XR Printable Vehicle Wrap Kit – 63" x 164'
Produce professional, long-lasting vehicle graphics with the Metamark MetaCast MDC XR Printable Vehicle Wrap Kit. This complete 63-inch matched wrap system combines premium cast printable vinyl with MetaGuard MGC cast overlaminate for full vehicle wraps, partial wraps, fleet graphics and other demanding applications.
The wider 63-inch roll offers increased coverage for large vehicle panels and can help installers reduce seams on commercial vans, trucks, trailers and fleet vehicles.
MetaCast MDC XR features Metamark’s advanced MetaGlide XR adhesive technology. Its grey solvent-based adhesive provides optimized repositionability and adhesion, while the structured micro-channel liner helps release trapped air during installation.
The film is engineered to conform over complex curves, deep channels and recesses while delivering excellent print quality, color vibrancy and long-term dimensional stability.
The included MetaGuard MGC overlaminate is specifically matched to MetaCast MDC print media. The matched cast construction helps reduce the risk of tunneling and delamination while protecting printed graphics from abrasion, weathering and everyday exposure.
Available Kit Finishes
- Gloss Kit: MetaCast MDC XR printable vinyl with MetaGuard MGC-005 clear gloss overlaminate.
- Matte Kit: MetaCast MDC XR printable vinyl with MetaGuard MGC-002 clear matte overlaminate.
Kit Includes
- One 63" x 164' roll of Metamark MetaCast MDC XR white gloss printable cast wrap film
- One 63" x 164' roll of Metamark MetaGuard MGC cast wrap overlaminate
- Choice of clear gloss or clear matte laminate
Key Features
- Complete matched printable vehicle wrap and laminate system
- 63-inch width provides increased coverage for large vehicle panels
- Helps reduce seams on vans, trucks, trailers and fleet vehicles
- Designed for full wraps, partial wraps and commercial fleet graphics
- Premium cast construction for demanding wrap applications
- Suitable for complex curves, deep channels and recesses
- MetaGlide XR micro-channel air-release adhesive
- Optimized repositionability for more efficient installation
- Grey adhesive provides dependable coverage and blockout
- Excellent print quality and color vibrancy
- Matched overlaminate helps prevent tunneling and delamination
- Engineered for long-term dimensional stability
- Up to 10-year unprinted outdoor durability under applicable conditions
- Backed by the applicable Metamark MetaSure warranty
- REACH and RoHS compliant
- Self-extinguishing film construction
Printable Film Specifications
- Product: MetaCast MDC XR
- Roll Size: 63" x 164'
- Face Film: Premium cast vinyl
- Film Thickness: 50 micron nominal, approximately 2 mil
- Finish: White gloss
- Adhesive: MetaGlide XR grey solvent-based adhesive
- Air Release: Structured micro-channel technology
- Liner: 140 gsm structured PE layflat liner
- Application Temperature: 50°F to 104°F
- Service Temperature: -4°F to 212°F
- Compatible Inks: Solvent, eco-solvent, latex and compatible UV
Overlaminate Specifications
- Product: MetaGuard MGC
- Roll Size: 63" x 164'
- Face Film: Cast vinyl
- Film Thickness: 40 micron nominal, approximately 1.6 mil
- Adhesive: Permanent solvent-based adhesive with UV inhibitors
- Liner: 140 gsm PE layflat liner
- Available Finishes: Clear gloss or clear matte
- Application Temperature: 50°F to 104°F
- Service Temperature: -22°F to 230°F
Recommended Applications
- Full vehicle wraps
- Partial vehicle wraps
- Commercial van wraps
- Truck and trailer graphics
- Fleet graphics and business branding
- Motorsport and racing graphics
- Vehicle panels with channels and recesses
- Complex curved and three-dimensional surfaces
Printing and Laminating Recommendations
Always perform a test print and verify the correct printer profile, ink compatibility and heater settings before production. Allow the printed media to cure completely before lamination and installation.
For solvent and eco-solvent printing, Metamark recommends allowing a minimum of 48 hours for the inks to outgas before overlaminating or applying the graphic. Heavy ink coverage and dark, saturated colors may require additional drying time.
The MetaGuard MGC overlaminate is intended for cold lamination. Some UV inks may not be suitable for highly conformable vehicle wrap applications. Always confirm ink flexibility and compatibility before production.
Installation Notes
This product is intended for professional dry application. Proper surface preparation, installation techniques, heating and post-heating procedures are required, particularly when applying the film into deep channels and recesses.
Important: Outdoor durability and warranty coverage depend on the printing system, ink, exposure conditions, geographic location, surface orientation, preparation and installation. Refer to the current Metamark technical literature and warranty documentation before production and installation.
