Product Description
Arlon Series 3510 is a 3.2-mil (80 micron) economy calendered overlaminate with a clear, permanent pressure-sensitive adhesive — engineered to protect short-term signage, banners, POP displays, and promotional graphics for up to 3 years outdoors. Available in gloss and matte finishes, with cold-lamination convenience and HP Latex Ink certification.
Economy Protection for Promotional Calendered Graphics
Series 3510 is Arlon's value-priced overlaminate built to pair with economy calendered print media like Arlon Series 2500 and similar promotional films. The 3.2-mil calendered construction adds a protective layer against UV exposure, abrasion, moisture, and everyday handling — extending the service life of printed graphics without the cost of a premium cast laminate.
The clear, permanent pressure-sensitive adhesive bonds quickly at room temperature and the two-sided polycoated liner delivers excellent lay-flat behavior through your laminator, reducing edge curl, tunneling, and waste on long production runs.
Key Features
- 3.2-mil (80 micron) calendered construction — cost-effective protection for short-to-medium term graphics
- Clear permanent adhesive with strong initial tack and high ultimate bond strength
- Two-sided polycoated liner for excellent lay-flat properties and clean, reliable feeding
- Cold lamination — no heat required, compatible with virtually any roll laminator
- Excellent printability on Eco-Solvent, Solvent, and Latex print systems (also usable as a printable overlaminate)
- Gloss or matte finish options to match creative intent
- 3-year outdoor durability rating for vertical exterior applications
- HP Latex Inks certified for guaranteed compatibility
Ideal Applications
Retail & POP
Point-of-purchase displays, shelf talkers, kiosks, end-cap graphics, and in-store promotional signage.
Short-Term Signage
Event graphics, construction barricades, real estate signage, political campaign boards, and seasonal promotions.
Banners & Wall Graphics
Protects calendered banner prints and flat wall graphics from scuffing, fingerprints, and mild outdoor exposure.
Interior & Exterior Flats
Rated for both indoor and outdoor use on flat substrates — aluminum, corrugated plastic, PVC, foamboard, and acrylic.
Technical Specifications
| Property | Typical Value |
|---|---|
| Film Type | Calendered printable overlaminate, pressure-sensitive |
| Thickness | 3.2-mil (80 micron) |
| Surface Finish | Gloss: 70–90 gloss units (60° reflection) | Matte: 1.5–10 gloss units |
| Adhesive | Clear, permanent pressure-sensitive |
| Liner | Two-sided polycoated, excellent lay-flat |
| Tensile Strength | ≥ 15 lb/in (≥ 2.68 kg/cm), web direction |
| Elongation | ≥ 150% |
| Peel Adhesion (15 min) | ≥ 1.5 lb/in (≥ 0.27 kg/cm) — PSTC-1, 70°F |
| Peel Adhesion (24 hrs) | 10.7 N / 25 mm — PSTC-1, 70°F |
| Liner Release | 125 g / 2 in (24.6 g/cm) — TLMI Release at 90° |
| Dimensional Stability | 5-mil (0.13 mm) — 158°F / 70°C, 48 hrs, aluminum panel |
| Application Temp Range | 50°F to 90°F (10°C to 32°C) — clean, dry substrate |
| Service Temp Range | -20°F to 150°F (-29°C to 65°C) |
| Shelf Life | 1 year from factory shipment (stored at 70°F / 50% RH) |
| Outdoor Durability | Up to 3 years, vertical exterior exposure |
| Ink Compatibility | Eco-Solvent, Solvent, Latex (HP Latex Certified) |
| Lamination Method | Cold lamination — no heat required |
Recommended Print Media Pairings
Series 3510 is engineered as the companion overlaminate for Arlon's economy calendered print films. Pair it with:
- Arlon Series 2500 — economy calendered printable vinyl (the most common pairing)
- Other 3- to 4-mil calendered promotional print media on Eco-Solvent, Solvent, or Latex platforms
- Calendered banner films where a flat, smooth protective topcoat is preferred over a textured cast laminate
Frequently Asked Questions
Why Buy Arlon Series 3510 from KG Supplies
- Overnight delivery across Arizona, Nevada, New Mexico, and Colorado from our Phoenix warehouse
- Nationwide UPS shipping with rolls kept in stock and ready to ship
- Authorized Arlon distributor — full product warranty, fresh inventory, accurate lot traceability
- Expert printer and laminator support from our in-house team
Need help choosing between calendered and cast overlaminates, or matching 3510 to your print media? Call KG Supplies at (602) 272-8655 or email Sales@kgsupplies.com.
