Product Description
Arlon Series 3210 is a 1.3-mil (35 micron) premium cast vinyl overlaminate with clear, permanent pressure-sensitive adhesive — the lightweight cast laminate engineered for excellent conformability on vehicle wraps, fleet graphics, and long-term signage. Built-in UV inhibitors and a 7-year outdoor durability rating deliver standard-grade protection in a lighter, more flexible film. Available in Gloss and Matte finishes.
Lightweight Premium Cast Overlaminate Built for Conformability
Series 3210 is Arlon's lightweight premium cast overlaminate — a 1.3-mil cast vinyl with clear, permanent pressure-sensitive adhesive and integrated UV inhibitors. The thinner film delivers the same protection as Arlon's standard-weight overlaminates while offering exceptional conformability during installation, making it the preferred choice for installers wrapping over rivets, channels, and complex curves.
At ≥200% elongation, 3210 stretches into recesses and around 3D shapes without lifting or tunneling. The two-finish range — high-gloss for color depth and matte for glare-free signage — covers the most-requested finish options for vehicle wraps and long-term graphic applications.
Key Features
- 1.3-mil (35 micron) premium cast vinyl — lightweight construction for superior conformability
- Excellent conformability with ≥200% elongation for wraps, rivets, and corrugated surfaces
- UV inhibitors integrated to extend printed-graphic life
- 7-year outdoor durability on vertical exterior applications
- Two finishes available: Gloss for color pop, Matte for glare-free signage
- Wide service temperature range: -40°F to 175°F
- Strong peel adhesion: 3.0 lbs/in (15 min) for secure bonding
- 2-year shelf life from factory shipment
- Cold lamination — no heat required
Choose Your Finish
Gloss
80–90 Gloss UnitsMaximum color depth and saturation with extra pop on printed graphics. The standard choice for vehicle wraps, fleet branding, and retail graphics where visual impact drives results.
Matte
< 10 Gloss UnitsDeep low-glare finish that eliminates reflection. Ideal for indoor signage, architectural applications, photography graphics, and luxury fleet wraps where matte is on-brand.
Ideal Applications
Vehicle & Fleet Wraps
Full and partial vehicle wraps, commercial fleet graphics, food trucks, and trailers — where lightweight conformability over rivets, channels, and curves matters most.
Long-Term Outdoor Signage
Permanent and semi-permanent outdoor signage, building wraps, branded environments, and architectural graphics with 5–7 year service-life expectations.
Kiosks & POP Displays
Premium-feel protection for point-of-purchase displays, branded kiosks, and high-traffic retail graphics that need to stay vibrant for the long haul.
Corrugated Substrates
Conforms into rivets, channels, and corrugations on trailers, trucks, and industrial surfaces (apply at 60°F+ on textured substrates).
Technical Specifications
| Property | Typical Value |
|---|---|
| Film Type | Premium cast vinyl overlaminate, pressure-sensitive |
| Thickness | 1.3 mil (35 micron) |
| Surface Finish | Gloss: 80–90 GU | Matte: < 10 GU (60° reflection) |
| Adhesive | Clear, permanent pressure-sensitive |
| Tensile Strength | ≥ 6.5 lb/in (≥ 1.2 kg/cm), web direction |
| Elongation | ≥ 200% |
| Peel Adhesion (15 min) | 3.0 lbs/in (0.535 kg/cm) — PSTC-1, 70°F (21°C) |
| Liner Release | 37 g / 2 in (7.28 g/cm) — TLMI Release at 90° |
| Dimensional Stability | < 10-mil (0.25 mm) shrinkage — 158°F / 70°C, 48 hrs |
| Application Temp (Flat) | 40°F to 100°F (4.4°C to 38°C) |
| Application Temp (Corrugated / Rivets) | 60°F to 100°F (15°C to 38°C) |
| Service Temp Range | -40°F to 175°F (-40°C to 79°C) |
| Shelf Life | 2 years from factory shipment (stored at 70°F / 50% RH) |
| Outdoor Durability | Up to 7 years, vertical exposure |
| UV Protection | UV inhibitors integrated into formulation |
| Lamination Method | Cold lamination — no heat required |
Frequently Asked Questions
Why Buy Arlon Series 3210 from KG Supplies
- Overnight delivery across Arizona, Nevada, New Mexico, and Colorado from our Phoenix warehouse
- Nationwide UPS shipping with rolls kept in stock and ready to ship same-day
- Authorized Arlon distributor — full product warranty, fresh inventory, accurate lot traceability
- Expert wrap and laminator support from our in-house team to spec the right cast laminate for the project
Need help spec'ing the right Arlon cast overlaminate for your wrap or signage project? Call KG Supplies at (602) 272-8655 or email Sales@kgsupplies.com — we'll match the right laminate to your print media and finish requirements.
